00-02 KTM 520 EXC / 00-02 KTM 520 SX / 03-06 KTM 525 EXC / 03-06 KTM 525 SX JE 95mm 13:1 Stock Bore Piston Kit

JE PISTONS

MSRP: $277.63
$218.50
(You save $59.13 )
(No reviews yet) Write a Review
SKU:
513-027-101-221777
Availability:
Usually Ships in 24 Hours
Shipping:
Calculated at Checkout
Manufacturers Part #:
221777
Replacement Parts:
Replacement Parts are Available for these Pistons, Please See Description Below.
Adding to cart… The item has been added

JE Pistons

Fitment:
-00-02 KTM 520 EXC
-00-02 KTM 520 SX
-03-06 KTM 525 EXC
-03-06 KTM 525 SX

Bore Size: 95mm (Stock Bore).

Replacement Components are available, please see below.

Includes:
-JE Forged Piston
-JE Piston Ring Pack
-JE Wrist Pin
-1 Set of JE Piston Pin Clips

Piston Specs:

95mm 13:1 Pistons (221777):
-Bore Diameter: 95.00mm
-Piston Head Type: Dome
-Cylinder Head: 4 VALVE 520
-Piston Pin Outside Diameter: 0.787"
-Piston Pin Length: 2.050"
-Piston Pin Material: 9310 Steel
-Ringset Included: Yes
-Top Compression Ring Thickness: 0.048"
-Oil Ring Thickness: 0.0795"
-Piston Material: 2618 Aluminum Forged
-Forging Type: FSR
-Piston Avg Weight: 270 g
-Pin Wall Thickness: 0.160"

13:1 Piston requires minimum of 100+ Octane Fuel. Pistons are a 2-Ring Piston Design for lightweight racing applications.

Replacement Components:

Replacement Ring Pack:
-ZS9500 (Fits All Pistons)

Replacement Wrist Pin:
-787-2050-16-93C (Fits All Pistons)

Replacement Wrist Pin Clips:
-787-050-MW (Fits All Pistons)
